IFM PV7601 PRESSURE SWITCH
Quick Overview
Manufactured By: IFM
Manufacturer Part Number: PV7601
IMS Product Code: 2132161
Packaging: Sold Individually
Description:
Ifm PV7601 Pressure Switch
Electronic pressure sensor with IO-Link for industrial applications
Specifications
- Measuring range: 0...250 bar, 0...3626 psi, 0...25 MPa
- Process connection: 1/4" NPT external thread, M5 internal thread
- Operating voltage: 18...30 DC
- Number of digital outputs: 2
- Output signal: switching signal; IO-Link
- Pressure rating: 625 bar, 9060 psi, 62.5 MPa
- Min. bursting pressure: 1200 bar, 17400 psi, 120 MPa
- Medium temperature: -40...90 degrees C
- IO-Link revision: 1.1
- Transmission type: COM2 (38.4 kBaud)
