INVENSYS AG13B020 ELECTRIC ACTUATOR
Quick Overview
Manufactured By: INVENSYS
Manufacturer Part Number: AG13B020
IMS Product Code: 2133692
Packaging: Sold Individually
Description:
Invensys AG13B020 Electric Actuator
Two Position Actuator, 120V, Normally Closed, 18" Leads
Specifications
- Actuator Type: Electric
- Actuator Use: Zone Valves
- Auxiliary Switch: No
- Control Signal: 2-Position (On/Off)
- Humidity: 5 to 95% non-condensing
- IP Protection Rating: IP10
- Lead Length: 18 in
- Leads and Connections: Appliance
- Loss of Power Type: Spring Return
- Mechanical Movement: Rotary
- Motor Type: AC Synchronous
- NEMA Protection Rating: NEMA 1
- Override: Automatic reset
- Position Indicator: Housing scale
- Power Consumption Running VA: 7.50 VA
- Power Input Frequency: 50 Hz, 60 Hz
- Power Input Voltage: 110 VAC, 115 VAC, 120 VAC
- Product Line: Schneider Electric
- Product Range: Erie PopTop
- Product Series: AG
- Stroke Running time: 24.0 s
- Temperature Ambient Operating Range: 0 to 93.3 C (32 to 200 F)
- Temperature Shipping and Storage Range: -40 to 71 C (-40 to 159.8 F)
- Weight: 2 lbs
- Dimensions: 4 × 5 × 3 in
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 8 In Stock
