JAE CONNECTORS MS3102A-14S-7P CIRCULAR CONNECTOR
Quick Overview
Manufactured By: JAE CONNECTORS
Manufacturer Part Number: MS3102A-14S-7P
IMS Product Code: 1922025
Packaging: Sold Individually
Description:
Jae Connectors MS3102A-14S-7P Circular Connector
3-position panel mount receptacle with threaded coupling and solder cup termination.
Specifications
- Number of Positions: 3
- Shell Size: 14S
- Contact Arrangement Code: 14S-7
- Contact Type: Pin
- Wire Termination Method: Soldering
- Contact Size: #16
- Material of Contact: Copper alloy
- Finish of Contact in Connecting Area: Silver plating
- Shell Material: Aluminum Alloy
- Shell Finish: Zinc
- Operating Temperature Range: -55 degrees C to +125 degrees C
- Coupling Style: Threaded
- Mounting Type: Panel Mount
- Mounting Feature: Flange
- Termination: Solder Cup
- Fastening Type: Threaded
- Orientation: N (Normal)
- Primary Material: Metal
- Color: Black
- Ingress Protection: -
- Material Flammability Rating: UL94 V-0
- Shielding: -
- Current Rating: 13 A
- Voltage Rating: 500 VAC
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships today if ordered in the next 4 hours and 23 minutes.
