JOHNSON CONTROLS V-3000-1 PNEUMATIC VALVE ACTUATOR
Quick Overview
Manufactured By: JOHNSON CONTROLS
Manufacturer Part Number: V-3000-1
IMS Product Code: 1835962
Packaging: Sold Individually
Description:
Johnson Controls V-3000-1 Pneumatic Valve Actuator
Pneumatic actuator for controlling HVAC valves, spring return operation, compatible with various Johnson Controls valve models.
Specifications
- Connection Size: 1/8 in
- Connection Type: Barbed
- Action: Spring return up
- Diaphragm Diameter: 4.5 in (11.4 cm)
- Diaphragm Effective Area: 8 sq. in. (20 sq. cm)
- Stroke: 5/16 in to 3/4 in (0.8 to 1.9 cm)
- Operating Temperature: -20°F to 150°F (-29°C to 66°C)
- Maximum Pressure: 25 psig (172 kPa)
- Dimensions: 3.5"H x 4.1"DIA (8.8 x 10.5 cm)
- Weight: 0.9 lb (0.41 kg)
- Mounting: Set screw to VG-7000 valve bonnet
- Spring Range: 3 psi to 13 psi
- Compatible Valve Sizes: 1/2 in, 3/4 in, 1-1/2 in
- Housing Material: Die Cast Aluminum
- Diaphragm Material: Synthetic Rubber
- Stem Material: Stainless Steel
