JOHNSON CONTROLS VG7241GT+7150G0 1/2" 2-WAY GLOBE VALVE
Quick Overview
Manufactured By: JOHNSON CONTROLS
Manufacturer Part Number: VG7241GT+7150G0
IMS Product Code: 1834394
Packaging: Sold Individually
Description:
Johnson Controls VG7241GT+7150G0 1/2" 2-Way Globe Valve
1/2" 2-Way Globe Valve with Electric Actuator
Specifications
- Product Series: VG7000 Electric Control Valves
- Capacity: 4.6 Cv
- Pipe Size: 0.5 "
- Connection Type: Threaded
- Max Static Pressure: 400 psi
- Body Pattern: Two-Way Normally Open
- Valve Style: Control
- Medium Temperature Range: 35-284 degrees F
- Flow Characteristic: Equal Percentage
- Nominal Voltage: 24 VAC
- Fail-Safe Mode: Non-Spring
- Valve Size: 1/2"
- Connection: Female NPT
- Trim Material: Brass
- Close-Off Pressure: 216 psi
- Actuator Type: VA-7150-1001
- Input Power: 20..30 VAC
- Control Type: On/Off or Floating Point
- Torque: 90 lb-f
- Runtime: 70..165 sec
- NEMA Rating: NEMA 1
- Fail Position: Last Position
- Country of Origin: Mexico
