JOHNSON CONTROLS VG7243ET+3003D 1/2" 2-WAY GLOBE VALVE
Quick Overview
Manufactured By: JOHNSON CONTROLS
Manufacturer Part Number: VG7243ET+3003D
IMS Product Code: 2149482
Packaging: Sold Individually
Description:
Johnson Controls VG7243ET+3003D 1/2" 2-Way Globe Valve
This Johnson Controls globe valve features a stainless steel body with a 1/2 inch size. It operates as a normally open, two-way valve with a flow coefficient of 1.8 Cv. The valve functions within a pressure range of 4 to 8 psi and includes an enclosure for protection.
Specifications
- Size: 1/2"
- Material: Stainless Steel
- Operation: Normally Open
- Type: 2-Way Valve
- Flow Coefficient: 1.8 Cv
- Pressure Range: 4-8 psi
- Connection: Female NPT
- Trim Material: Stainless Steel
- Body Rating: 250
- Effective Diaphragm Area: 8 sq. in.
- Close-off Pressure: 299 psig
- Flow Characteristic: Equal Percentage
- Operating Conditions: 35 F To 338 F (2 C To 170 C)
- Actuator Operating Conditions: -20 F To 150 F (-29 C To 66 C)
- Fail Position: Normally Open
- Spring Range: 4-8 psig
- Maximum Supply Air Pressure: 25 psig
- Actuator Type: V-3000-8003 enclosed pneumatic
