KEPCO ATE150-7M DC POWER SUPPLY
Quick Overview
Manufactured By: KEPCO
Manufacturer Part Number: ATE150-7M
IMS Product Code: 2137497
Packaging: Sold Individually
Description:
Kepco ATE150-7M DC Power Supply
DC Power Supply, 150V, 7A, 1050W
Specifications
- Form Factor: Rackmount
- Current: 7 A
- Power: 1050 W
- Type: CV/CC
- Voltage: 150 V
- Maximum Current Output: 7 amps
- Maximum Voltage Output: 150V
- Maximum Output Voltage: 0 to 150V
- Maximum Output Current: 0 to 7A
- Voltage Regulation: < 0.01% + 5mV
- Current Regulation: < 0.01% + 1mA
- Load Regulation: < 0.01% + 5mV
- Ripple and Noise: < 1mV rms
- Output Programming Accuracy: ±(0.05% + 5mV), ±(0.05% + 1mA)
- Output Voltage and Current Display Resolution: 0.1V, 0.01A
- Input Voltage: 100V to 240V AC, 50/60 Hz
- Interfaces: Analog control, remote sensing
- Dimensions (H x W x D): 5.25? x 19? x 15? (133 mm x 483 mm x 381 mm)
- Weight: 22 lbs (10 kg)
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 2 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
