KEYENCE ES-X38 PROXIMITY SWITCH AMPLIFIER
Quick Overview
Manufactured By: KEYENCE
Manufacturer Part Number: ES-X38
IMS Product Code: 2011645
Packaging: Sold Individually
Description:
Keyence ES-X38 Proximity Switch Amplifier
DC Type, NPN, Separate Amplifier Proximity Sensor Unit
Specifications
- Power supply: 12 to 24 VDC
- Current/power consumption: 25 mA max.
- Response time: 1 ms max.
- Operation mode: N.O./N.C. (switch-selectable)
- Control output: NPN: 100 mA (40 V) max. Residual voltage: 1 V max.
- Sensitivity adjustment: 15-turn trimmer
- Indicator: Output: Red LED
- Temperature characteristics: ±8% of detecting distance at 23°C within 0 to 50°C
- Ambient temperature: 0 to +50 degrees C
- Relative humidity: 35 to 85 % RH (No condensation)
- Weight: Approx. 67 g (including 2-m cable)
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 10 hours and 48 minutes.
