KEYENCE FD-XS20E FLOW SENSOR
Quick Overview
Manufactured By: KEYENCE
Manufacturer Part Number: FD-XS20E
IMS Product Code: 2145656
Packaging: Sold Individually
Description:
Keyence FD-XS20E Flow Sensor
Clamp-on micro flow sensor with rated flow range of 20 L/min. Supports various pipe materials and fluids. Offers high repeatability and environmental resistance.
Specifications
- Series: FD-X
- Type: Clamp-On Micro Flow Sensor
- Mounting Type: Clamp-On
- Supported Pipe Materials: Metal pipes, Plastic pipes (soft/hard)
- Supported Fluids: Liquids (water, oil, adhesive, grease, chemical solution, etc.)
- Supported Fluid Temperature: 0 to 100 degrees C (Pipe surface temperature)
- Maximum Rated Flow Rate: 20 L/min
- Display Resolution: 0.01/0.1 L/min
- Repeatability: ±15 % of RD (Response time 500 ms)
- Environmental Resistance: IP65/IP67, IP68G
- Ambient Temperature: -10 to 60 degrees C
- Relative Humidity: 35 % to 85 %RH
- Vibration Resistance: 10 to 55 Hz, double amplitude 1.5 mm
- Shock Resistance: 50 G 11 ms
- Material: Sensor head: PPS/PPSU, relay amplifier: PPS, cable: PVC, controller connector: PPS/PBT/POM
- Weight: Approx. 260 g
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 4 hours and 9 minutes.
