KEYENCE GL-R80H SAFETY LIGHT CURTAIN
Quick Overview
Manufactured By: KEYENCE
Manufacturer Part Number: GL-R80H
IMS Product Code: 2125809
Packaging: Sold Individually
Description:
Keyence GL-R80H Safety Light Curtain
Safety light curtain with 80 optical axes, hand-protection type, infrared LED light source, and aluminum main unit case.
Specifications
- Detection capability: ø0.98" ø25 mm
- Total length: 62.99" 1600mm
- No. of beam: 80
- Detection height: 62.20" 1580mm
- Protection height: 63.98" 1625mm
- Beam axis spacing/Lens diameter: 20 mm / ø5 0.79" / ø0.20"
- Detecting distance: 0.66 to 49.21' 0.2 to 15 m
- Effective aperture angle: Max. ±2.5° (When operating distance is 9.84' 3 m or more)
- Light source: Infrared LED (870 nm)
- Response time (OSSD): Wire synchronization: ON?OFF: 13.1 ms, OFF?ON: 58.4 ms, All blocked?ON: 89.1 ms; Optical synchronization: ON?OFF: 19.2 ms, OFF?ON: 67.6 ms, All blocked?ON: 113.7 ms
- Control output (OSSD output): 2 transistor outputs (PNP or NPN)
- Max. load current: 500 mA
- Power supply: 24 VDC ±20%, ripple (P-P) 10% or less, Class 2
- Current consumption: Transmitter: 77 mA, Receiver: 87 mA
- Material: Main unit case: Aluminum; Upper/lower case: Nylon (GF 30%); Front cover: Polycarbonate, SUS304
- Weight: Transmitter: 2230 g, Receiver: 2240 g
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 14 hours and 38 minutes.
