KEYENCE GT2-A50 DIGITAL CONTACT SENSOR
Quick Overview
Manufactured By: KEYENCE
Manufacturer Part Number: GT2-A50
IMS Product Code: 1927881
Packaging: Sold Individually
Description:
Keyence GT2-A50 Digital Contact Sensor
High-accuracy digital contact sensor with 50 mm measuring range
Specifications
- Detection System: Quartz glass scale, CMOS image sensor projection system, Absolute type (without tracking error)
- Measuring Range: 50 mm
- Resolution: 0.5 µm
- Indicated Accuracy: 3.5 µm (p-p)
- Measuring Force: Downward mounting: 3.2 N, Side mounting: 2.8 N, Upward mounting: 2.4 N
- Sampling Cycle: 1 ms
- Operation Indicator Light: 2-color LED (red, green)
- Enclosure Rating: IP67
- Pressure Resistance: 1 MPa
- Applied Pressure Range: 0.25 to 0.5 MPa
- Ambient Temperature: 0 to 55 degrees C
- Relative Humidity: 35 to 85 % RH
- Vibration Resistance: 10 to 55 Hz, Double amplitude 1.5 mm, 2 hours in each of the X, Y, and Z directions
- Materials: Main body case: Zinc die-casting; Cylinder part: Aluminium alloy; Air joint resin part: Polyacetal; Air joint metal part: Brass nickel plating; Indicator: Polyarylate
- Dust Boot: NBR
- Contact: TYPE304, 440C Stainless steel
- Weight: 405 g
- Country of Origin: Japan
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 18 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
For Parts or Repair (Special):
Has broken tip.
Availability: 2 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
