KEYENCE IV-HG10 SENSOR AMPLIFIER
Quick Overview
Manufactured By: KEYENCE
Manufacturer Part Number: IV-HG10
IMS Product Code: 2131635
Packaging: Sold Individually
Description:
Keyence IV-HG10 Sensor Amplifier
Sensor Amplifier for IV-HG series, main unit with various detection tools and network functions.
Specifications
- Type: Main unit
- Number of Detection tools: 16 tools, position adjustment tool: 1 tool
- Switch settings (programs): 32 programs
- Image history: When using a color type head: 100 images, when using a monochrome type head: 300 images
- Indicators: PWR/ERR, OUT, TRIG, STATUS, LINK/ACT
- Input Type: Non-voltage input/voltage input is switchable
- Inputs: 6 inputs (IN1 to IN6)
- Output Type: Open collector output NPN/PNP is switchable, N.O./N.C. is switchable
- Outputs: 8 outputs (OUT1 to OUT8)
- Ethernet Standard: 100BASE-TX/10BASE-T
- Ethernet Connector: RJ-45 8pin connector
- Network function: FTP client, EtherNet/IP™, PROFINET
- Power voltage: 24 VDC ±10 % (including ripple)
- Current consumption: 0.8 A or less
- Ambient temperature: 0 to +50 degrees C (No freezing)
- Relative humidity: 35 to 85 % RH (No condensation)
- Material: Main unit case: Polycarbonate
- Weight: Approx. 150 g
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
