KEYENCE LK-036 LASER DISPLACEMENT SENSOR
Quick Overview
Manufactured By: KEYENCE
Manufacturer Part Number: LK-036
IMS Product Code: 1913228
Packaging: Sold Individually
Description:
Keyence LK-036 Laser Displacement Sensor
CCD Laser Displacement Sensor for precise measurements.
Specifications
- Type: Sensor head High-precision Sensor head
- Reference distance: 30 mm 1.18"
- Measuring range: ±5 mm ±0.20"
- Light source Type: Visible red semiconductor laser
- Wavelength: 670 nm
- Output: 0.95 mW
- Laser Class: FDA (CDRH) 21CFR Part 1040.10 Class 2 Laser Product IEC 60825-1
- Spot diameter (at standard distance): Approx. 30 x 850 µm 0.001181 x 0.0335"
- Linearity: ±0.1% of F.S.
- Repeatability: 1 µm 0.000040"
- Analog output Voltage output: ±5 V (1 µm 0.000040"/mV)
- Impedance: 100 O
- Current output: 4 to 20 mA (Applicable load: 350 Omax.)
- Alarm output: NPN: 100 mA max. (40 V max.) (N.C.), Residual voltage: 1 V max.
- Sampling cycle: 512 µs
- Temperature characteristics: 0.01% of F.S./degrees C
- Rating Power voltage: 24 VDC ±10 %, Ripple (P-P) 10 % or less
- Maximum current consumption: 400 mA max.
- Environmental resistance Enclosure rating: IP67
- Ambient light: Incandescent or fluorescent lamp: 10,000 lux max.
- Ambient temperature: 0 to +50 degrees C 32 to 122 degrees F (No condensation)
- Relative humidity: 35 to 85 % RH (No condensation)
- Vibration resistance: 10 to 55 Hz, Double amplitude 1.5 mm 0.06", 2 hours in each of the X, Y, and Z directions
- Material: Aluminum die-cast
- Weight: Approx. 260 g (including cable)
- Series: LK
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
