KEYENCE LR-TB2000 ALL-PURPOSE LASER SENSOR
Quick Overview
Manufactured By: KEYENCE
Manufacturer Part Number: LR-TB2000
IMS Product Code: 2169158
Packaging: Sold Individually
Description:
Keyence LR-TB2000 All-Purpose Laser Sensor
All-Purpose Laser Sensor
Specifications
- Type: Cable
- Detectable Distance: 60 to 2000 mm 2.36" to 78.74"*1
- Spot Diameter: Approx. �4 mm �0.16"
- Light Source Type: Red laser (660 nm)
- Laser Class: Class 2 laser product (IEC60825-1,FDA (CDRH) Part1040.10*2)
- Mutual Interference Prevention Function: 4 units (when using the interference prevention function)
- Timer: OFF/OFF delay/ON delay/One-shot
- Response Time: 1 ms/10 ms/25 ms/100 ms/1000 ms selectable
- I/O Control Output: NPN open collector/ PNP open collector selectable 30 VDC or less, 50 mA or less, residual voltage: 2 V or less,N.O./N.C. selectable *3*4
- Protection Circuit: Protection against reverse power connection, power supply surges, output overcurrent, reverse output connection, and output surge
- Power Voltage: 20 to 30 VDC, including 10% ripple (P-P), Class 2 or LPS
- Current Consumption: 45 mA or less(without load)*5
- Environmental Resistance Enclosure Rating: IP65/IP67(IEC60529)
- Ambient Light: Incandescent lamp/Sunlight:10000 lux or less
- Ambient Temperature: -20 to +55�C -4to131�F(No freezing)
- Relative Humidity: 35to85%RH(No condensation)
- Vibration Resistance: 10to55Hz,Double amplitude1.5mm0.06",2hoursineachoftheX,Y,andZ directions
- Shock Resistance: 1000m/s^2 ,6timesineachoftheX,Y,andZd irections
- Material: Case:Zincdiecast(Nickelchromeplating),Indicatorcoverandbuttons:PES,Lenscoveranddisplay:PMMA(scratch-resistantcoatingspecifications),Cablebushing :PBT,Cable:PVC
- Accompanying Items: Instruction manual,Laserwarningandexplanationlabels
- Weight: Approx.125g(Includingcable)
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships on Monday, September 21, 2026
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
