KEYENCE N-42 DEDICATED COMMUNICATION UNIT
Quick Overview
Manufactured By: KEYENCE
Manufacturer Part Number: N-42
IMS Product Code: 1989061
Packaging: Sold Individually
Description:
Keyence N-42 Dedicated Communication Unit
Dedicated communication unit for RS-422A interface
Specifications
- Model: N-42
- Reader port Number of inputs: 1 (D-sub 9-pin connector)
- Power supply for the barcode reader: 5 VDC � 5% (630 mA)
- Communication method: RS-232C
- Output interface: RS-422A
- I/O terminal Input terminals Number of inputs: 1
- Input rating: 15 to 26 VDC, 10 mA maximum
- Maximum OFF current value: 1.0mA
- Output terminals Number of outputs: 2
- Output: NPN open collector
- Output rating: 30 VDC, 100 mA
- Leakage current (at OFF): 0.1mA or less
- Residual voltage (at ON): 1V or less
- Rating Power voltage: 24 VDC +10%, -20%
- Current consumption: 260 mA or less
- Environmental resistance Ambient temperature: 0 to +50 degrees C (32 to 122 degrees F)
- Relative humidity: 35 to 85% RH (No condensation)
- Vibration resistance: 10 to 55 Hz, Double amplitude 1.5 mm (0.06 in), 2 hours in each of the X, Y, and Z directions
- Weight: Approx. 100 g
- Power voltage: DC 24V <=100mA, Class 2
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
