KEYENCE PJ-V41 EXPANSION UNIT, LIGHT CURTAIN
Quick Overview
Manufactured By: KEYENCE
Manufacturer Part Number: PJ-V41
IMS Product Code: 1810158
Packaging: Sold Individually
Description:
Keyence PJ-V41 Expansion Unit, Light Curtain
Specifications:
- Type: Extension unit A
- Combination controller: PJ-V90, PJ-V91*1
- No. of beam axes: 4
- Beam axis spacing: 40 mm 1.57"
- Maximum optical axis number: 32 (PJ-V40 × 1 + PJ-V41 × 7)
- Detection area: 120 mm 4.72" (4 optical axes) to 1,240 mm 48.82" (32 optical axes)*2
- Detecting distance: 7m
- Detectable object: Opaque material with a diameter of 48 mm or more
- Light source: Infrared LED (peak wavelength : 880 nm)
- Operation format: Turned on when light is being applied to all optical axes
- Effective aperture angle: ±2.5° maximum (when the detecting distance is 3 m or more)*3
- Indicator lamp: A string of 8, 2-color LEDs (red and green) for the transmitter and receiver
New - Open Box (Special):
Set of 2
Availability: 3 In Stock
Ships today if ordered in the next 11 hours and 22 minutes.
