KEYENCE PS2-61 PHOTOELECTRIC AMPLIFIER
Quick Overview
Manufactured By: KEYENCE
Manufacturer Part Number: PS2-61
IMS Product Code: 2135665
Packaging: Sold Individually
Description:
Keyence PS2-61 Photoelectric Amplifier
Separate type photoelectric sensor amplifier unit, DC type, NPN output.
Specifications
- Power Supply: 12 to 24 VDC ±10%
- Current/Power Consumption: 45 mA max
- Response Time: 0.5 ms (1 ms at alternate frequency)
- Sensitivity Adjustment: 3-turn trimmer
- Operation Mode: LIGHT-ON/DARK-ON (switch-selectable)
- Control Output: 100 mA (40 V) max, Residual voltage: 1V max
- Alarm Output: 50 mA (40 V) max, Residual voltage: 1 V max
- Timer: ON-delay/OFF-delay/One-shot/Timer-OFF selectable (40 ms to 5 s)
- Buzzer: ON at control output-ON/ON at alarm output-ON/OFF selectable
- Protection Circuit: Reversed polarity, short-circuit protection, surge absorber
- Ambient Temperature: -10 to +50°C
- Relative Humidity: 35 to 85% RH (No condensation)
- Weight: Approx. 65 g (including 2 m cable)
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
