LAMBDA JWS100-24/508 AC-DC POWER SUPPLY
Quick Overview
Manufactured By: LAMBDA
Manufacturer Part Number: JWS100-24/508
IMS Product Code: 2164674
Packaging: Sold Individually
Description:
Lambda JWS100-24/508 AC-DC Power Supply
AC-DC converter with 24V output, 4.5A maximum current, and 85-265V AC or 120-330V DC input.
Specifications
- Input Voltage Range (AC): 85 to 265Vac
- Input Voltage Range (DC): 120 to 330Vdc
- Rated Output Voltage (DC): 24Vdc
- Output Voltage Range (DC): 21.6 to 26.4Vdc
- Maximum Output Current: 4.5A
- Maximum Output Power: 108W
- Width: 50mm Nom. (1.97in Nom.)
- Height: 92mm Nom. (3.62in Nom.)
- Depth: 188mm Nom. (7.40in Nom.)
- Weight: 700g Typ. (1.5lbs Typ.)
- Operating Temperature Range: -10 to 55°C
- Cooling: Convection
- Efficiency: 79% Typ.
- Safety Standard (Certified): CSA C22.2 No.60950-1, EN60950-1, UL60950-1, CSA C22.2 No.14, UL508
- Model Type: JWS Series
- Mounting Type: Chassis Mount
- Country of Manufacture: China
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 2 In Stock
Ships today if ordered in the next 7 hours and 18 minutes.
