LAUREL ELECTRONICS LTA212R1 1/8 DIN PANEL METER
Quick Overview
Manufactured By: LAUREL ELECTRONICS
Manufacturer Part Number: LTA212R1
IMS Product Code: 2132147
Packaging: Sold Individually
Description:
Laurel Electronics LTA212R1 1/8 DIN Panel Meter
Digital Panel Meter for process signals
Specifications
- Display: 5 LED digits, 7-segment, 14.2 mm (.56")
- Display Color: Red or green LED
- Display Range: -99999 to 99999
- Input Range: ±200.00 mV to ±600V or ±2 mA to ±5A
- Accuracy: 0.01% of reading ± 2 counts
- A-to-D Technique: Concurrent Slope (Pat 5,262,780)
- Power Supply Voltage: 85-264 Vac or 90-300 Vdc, 12-32 Vac or 10-48 Vdc
- Power Supply Frequency: DC or 47-63 Hz
- Operating Temperature: -40°C to 70°C
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 95% at 40°C, non-condensing
- Protection: NEMA-4X (IP-65) when panel mounted
- Enclosure: 1/8 DIN, high impact plastic, UL 94V-0, color: black
- Dimensions: 4.68" x 2.45" x 5.64" (119 mm x 62 mm x 143 mm) (W x H x D)
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 3 In Stock
Ships today if ordered in the next 9 hours and 53 minutes.
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships today if ordered in the next 10 hours and 53 minutes.
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 2 In Stock
Ships today if ordered in the next 10 hours and 53 minutes.
