LEESON 113473.00 1/2 HP WASHDOWN MOTOR
Quick Overview
Manufactured By: LEESON
Manufacturer Part Number: 113473.00
IMS Product Code: 2143129
Packaging: Sold Individually
Description:
LEESON 113473.00 1/2 HP Washdown Motor
Three-phase C-face washdown AC motor with 1/2 HP output, 208-230/460V AC voltage, 1725 RPM speed, 56C frame size, TENV enclosure, and rolled steel frame.
Specifications
- phase: 3
- horsepower: 1/2
- voltage: 208-230/460 VAC
- speed: 1725 rpm
- enclosure: TENV
- frame: 56C
- mount: C-face
- material: Rolled Steel
- duty: Continuous
- insulation class: F
- service factor: 1.15
- efficiency: 78.5%
- ambient temperature: 40 degrees C
- shaft diameter: 0.625 in
- shaft extension: 1.88 in
- weight: 25 LB
- IP code: 55
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 9 hours and 22 minutes.
