MACAIR UA1200A ULTRA SERIES NON-CYCLING AIR DRYER 575V 3PH 60HZ
Quick Overview
Manufactured By: MACAIR
Manufacturer Part Number: UA1200A-575V-3PH-60HZ
IMS Product Code: 1792922
Packaging: Sold Individually
Description:
MACAIR UA1200A Ultra Series Non-Cycling Air Dryer 575v 3ph 60hz
MECHANICAL SPECS
- Inlet Air Flow: 1200 SCFM
- Inlet Pressure: 100 PSIG
- Inlet Temp: 100 F
- DEWPOINT TEMP: 38 F
- COOLING AIR FLOW: 4240 CFM
- PRESSURE LOSS, DESIGN: 2.8
- CONDENSER TYPE: Air Cooled
- WEIGHT: 910 LBS
- IN & OUT CONNECTION: 3” FPT
- DRAIN CONNECTION: 3/8” O.D.
- MAXIMUM AMBIENT TEMP: 110 F
- MINIMUM AMBIENT TEMP: 40 F
- MAXIMUM AIR PRESSURE: 232 PSIG
ELECTRICAL SPECS
- Locked Rotor Amps: 75
- Rated Load Amps: 9.3
- Max Fuse: 20
- Power Connection: 460-3-60
- Full Load Power (WATTS): 7400
STANDARD FEATURES
- Aluminum block heat exchanger
- Air to air pre-cooler/re-heater
- Stainless Steel mesh separator
- Tecumseh Compressor
- Suction Pressure Gauge
- Discharge Pressure Gauge
- On-Off Switch w Power On Light
- Compressor Overload
- Heavy duty industrial powder coated steel cabinet
- Environmentally friendly R404a refrigerant
- Refrigerant access ports
- Expansion valve
- Hot Gas Bypass Valve
- Filter Drier
- Programmable electronic drain valve with y-strainer
- Easy access cabinet design allows for ease of service.
- Made In USA
OPTIONAL FEATURES
- Pre-filter and after-filters mounted on the dryer
- 575-3-60 or 230-3-60
- Additional pressure and temperature gauges
- Ambient Air Filter
