MARTIN JA 11/16 QD BUSHING
Quick Overview
Manufactured By: MARTIN
Manufacturer Part Number: JA 11/16
IMS Product Code: 2144510
Packaging: Sold Individually
Description:
Martin JA 11/16 QD Bushing
Quick disconnect bushing made of cast iron with a finished bore and keyway.
Specifications
- Bushing Size: JA
- Bore Type: Finished w/ Keyway
- Keyway Size: 3/16 x 3/32 in
- Bore Diameter: 0.6875 in
- Flange Outside Diameter: 2 in
- Flange Thickness: 0.375 in
- Length Through Bore: 1.0625 in
- Material: Cast Iron
- Screw Torque: 60 in-lbs
- Barrel Diameter: 1-3/8 in
- Barrel Length: 0.687 in
- Bolt Circle Diameter: 1.665 in
- Number Of Bolt Holes: 3
- Screw Thread Size: #10-24
- Screw Length: 1 in
- Weight: 0.39 lbs
- Mounting Type: Reverse
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 10 hours and 55 minutes.
