MARTIN SDS 24MM QD BUSHING
Quick Overview
Manufactured By: MARTIN
Manufacturer Part Number: SDS 24MM
IMS Product Code: 1906050
Packaging: Sold Individually
Description:
Martin SDS 24MM QD Bushing
A quick disconnect bushing with a 24 mm bore diameter, made of steel.
Specifications
- Bushing Size: SDS
- Bore Type: Finished w/ Keyway
- Bore Diameter: 24 mm
- Flange Diameter: 3.18 in
- Flange Thickness: 0.43 in
- Hub Diameter: 3-1/2 in
- Overall Length: 1.31 in
- Barrel Diameter: 2.187 in
- Keyway Size: 8 x 3.3 mm
- Material: Steel
- Number of Bolt Holes: 3
- Bolt Circle Diameter: 2.69 in
- Screw Size: 1/4-20 x 1-3/8 in
- Torque Rating: 5000 in-lb
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 7 In Stock
Ships today if ordered in the next 15 hours and 14 minutes.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 15 hours and 14 minutes.
