MCGILL CF5/8-SB CYLINDRICAL CAM FOLLOWER
Quick Overview
Manufactured By: MCGILL
Manufacturer Part Number: CF5/8-SB
IMS Product Code: 1803429
Packaging: Sold Individually
Description:
McGill CF5/8-SB Cylindrical Cam Follower
Stud type cam follower with cylindrical roller, sealed design, and hex hole. Made of bearing steel with black oxide finish. 5/8 inch roller diameter, 7/16 inch roller width, 1/4 inch stud diameter, and 3/4 inch stud length.
Specifications
- Ability to Relubricate: No
- Bearing Element: Needle Roller - Full Complement
- Bearing Type: Needle Roller
- Clamping Torque: 35 in-lbf
- Closure Type: Sealed
- Dynamic Load Capacity: 955 lbs
- Finish/Coating: Black Oxide Finish
- Head Type: Hex Hole
- Height: 1.75 inches
- Length: 1.75 inches
- Lubrication Hole Location: Stud End
- Material: Steel
- Maximum RPM: 9200 rpm
- Radial Static Load Capacity: 1215 lbs
- Roller Diameter: 0.625 inches
- Roller Material: Bearing Steel
- Roller Shape: Cylindrical
- Roller Type: Needle Roller
- Roller Width: 0.4375 inches
- Series: Inch CAMROL (CF)
- Static Load Capacity: 1215 lbs
- Stud Diameter: 0.25 inches
- Stud Length: 0.75 inches
- Stud Type: CF - Standard Stud
- Thread Length: 5/16 inches
- Thread Size: 1/4-28
- Tolerance Class: P0 Equivalent
- Type: Sealed Stud Cam Follower with Hex
- Weight: 0.06 lbs
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 20 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
