MERSEN FSPDB2A POWER DISTRIBUTION BLOCK
Quick Overview
Manufactured By: MERSEN
Manufacturer Part Number: FSPDB2A
IMS Product Code: 1913991
Packaging: Box of 3
Description:
Mersen FSPDB2A Power Distribution Block
Finger-safe power distribution block with 1 pole, 175A rating, tin-plated aluminum, and IP20 protection.
Specifications
- rated voltage AC UL: 1500 V
- rated voltage DC UL: 1500 V
- frequency: 50/60 Hz
- ampere rating: 175 A
- number of poles: 1
- connector material: tin-plated aluminum
- number of openings per pole (primary): 1
- number of openings per pole (secondary): 4
- connector type: box
- hole diameter (primary): 0.45 in
- hole diameter (secondary): 0.32 in
- torque rating (primary): 2/0-#1 100; #2-#6 80; #8-#14 35;
- torque rating (secondary): #2-#6 80; #8-#14 35;
- wire range (primary): 2/0-#14
- wire range (secondary): #2-#14
- installation mounting: screw mount or DIN rail
- product width: 2.21 in
- product length: 3.45 in
- product height: 2.21 in
- product group: power distribution blocks
- body/insulating material: nylon
- product weight: 0.7 lb
- protection rating: IP20
- color: gray
- approvals: CSA, UR
Used (Special):
2 are connected.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
