MISUMI LHMSW25 FLANGED LINEAR BUSHING
Quick Overview
Manufactured By: MISUMI
Manufacturer Part Number: LHMSW25
IMS Product Code: 2122052
Packaging: Sold Individually
Description:
Misumi LHMSW25 Flanged Linear Bushing
Center flanged linear ball bearing with double ball recirculation
Specifications
- Outer Cylinder Material: 52100 Bearing Steel
- Balls Material: 52100 Bearing Steel
- Retainer Material: Plastic (Duracon M90)
- Seals Material: Nitrile Rubber
- Ambient Operating Temp.: -20~ 80 degrees C
- Seals Operating Temp.: -20~120 degrees C
- Type: Flange
- Motion: Linear Motion
- Style: Standard
- Lubrication Type: Standard
- Ball Recirculating Type: Double
- Precision: High Grade
- Seals: With Seal
- Counterbored Hole: Standard
- For Shaft Size: 25 mm
- Overall Length L: 112 mm
- Flange Type: Center Flanged
- O.D. D: 40 mm
- Basic Dynamic Load Rating: 1560 N
- Basic Static Load Rating: 3140 N
- Eccentricity: 20 um
- Flange Shape: Square Flanged
- Greased filled: Standard (Rust Prevent Oil)
- Inner Contact Circle Tolerance (Negative Side): -0.012 mm
