MULTI COMP MC19681 AC AXIAL FAN
Quick Overview
Manufactured By: MULTI COMP
Manufacturer Part Number: MC19681
IMS Product Code: 1865432
Packaging: Sold Individually
Description:
Multi Comp MC19681 AC Axial Fan
AC Axial Fan with lubricated sleeve bearing and terminal power connection. Die-cast aluminum frame and thermoplastic PBT impeller. Counter-clockwise direction of rotation viewed from front of fan blade and reliable shaded pole motor construction.
Specifications
- Nominal Rated Voltage AC: 220V to 240V
- Fan Frame Type: Square
- Fan Frame Size: 119mm
- External Depth: 38.5mm
- Bearing Type: Sleeve Bearing
- Air Flow - CFM: 105CFM
- Noise Rating: 48dBA
- Power Rating: 19W
- Rated Speed: 2550rpm
- Power Connection Type: Terminals
- Current Rating: 125mA
- Air Flow - m3/min: 2.97m³/min
- Type: Axial Fan
- Mounting Type: Through-hole (screw mount)
