NACHI UVN-1A-1A4-2.2-4-12 VARIABLE VANE PUMP
Quick Overview
Manufactured By: NACHI FUJIKOSHI CORP
Manufacturer Part Number: UVN-1A-1A4-2.2-4-12
IMS Product Code: 2142617
Packaging: Sold Individually
Description:
Nachi UVN-1A-1A4-2.2-4-12 Variable Vane Pump
Variable volume vane Uni-Pump. An energy-efficient, high performance, long life, low noise, lightweight, compact design.
Specifications
- Series: UVN
- Pump Size: 1
- Mounting Method: A: Foot Type Mounting
- Discharge Rate: 7.6 gpm (max)
- Discharge Rate: 24/29 L/min
- Flow Characteristics: A: Constant Discharge Type
- Pressure Range (psi): 797 - 1160 psi
- Max Pressure: 8 MPa
- Pressure Adjustment Range: 5.5 - 8.0 MPa
- Pump Capacity: 16.1 cm³/rev
- Motor Output (hp): (3 hp)
- Motor Output: 2.2 kW
- Motor Poles (Voltage): 4
- Voltage: AC200V (50/60 Hz), AC220V (60Hz)
- Design Number: 12
- Weight (lb/kg): 66.2 / 30
- Brand: Nachi
- Country/Region of Manufacture: Japan
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
