NEDAP 9945466 LONG RANGE UHF READER
Quick Overview
Manufactured By: NEDAP
Manufacturer Part Number: 9945466
IMS Product Code: 2143741
Packaging: Sold Individually
Description:
Nedap 9945466 Long Range UHF Reader
Long-range UHF reader for vehicle access control, reading passive UHF tags up to 5 meters.
Specifications
- Brand: Nedap Inc
- Operating Frequency: 902-928 MHz
- Detection Range: Up to 5 meters [16.4 ft] with passive Nedap UHF tags
- Power: 12...24 VDC +10% linear supply recommended
- Current Consumption: 1A @12VDC, 0.5@24VDC
- Output: Wiegand, clock & data
- Relay Output: 1 relay output (NO, common, NC), 24 VDC 2A
- Input: 1 dry contact or TTL
- Operating Temperature: -30...+60°C [-22...+140°F]
- Protection: IP65 [approx.NEMA4x]
- Housing: Aluminium chassis with UL94 ABS cover
- Dimensions: 200 x 220 x 45 mm [7.9 x 8.7 x 1.8 in]
- Weight: 0.75 kg [1.65 lbs]
- Certifications: CE, FCC
- Encrypted Air Interface: According to ISO 18000-6 C
- Communication Protocols: CR/LF, DC2/DC4 and various OEM protocols
- Interfaces: RS232, RS422 and USB service interface
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 3 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
