NETGEAR AGM731F SFP TRANSCEIVER
Quick Overview
Manufactured By: NETGEAR
Manufacturer Part Number: AGM731F
IMS Product Code: 2146997
Packaging: Sold Individually
Description:
Netgear AGM731F SFP Transceiver
1G Ethernet Fiber Module for Managed Switches, 1000Base-SX, LC duplex connector
Specifications
- Connector: LC duplex connector
- Fiber connectivity: Gigabit Ethernet “short-reach”
- Distance with 50/125µm OM4 multimode fiber cables: 1,000 m
- Distance with 50/125µm OM3 multimode fiber cables: 550 m
- Distance with 62.5/125µm OM1 multimode fiber cables: 275 m
- Data transfer rate: 1 Gbps
- Receiver and transmitter capability: full-duplex
- Supported fiber cables: 50um and 62.5um multimode
- Operating temperature: 32 to 104 degrees Fahrenheit
- Operating humidity: 10 to 90%
- Dimensions: 0.5-in W, 2.6-in D and 0.4-in H
- Standards: IEEE 802.3z and UL 1950
- Max. Power Consumption: 0.8W
- Commercial Temperature Range: 0 to 70°C (32 to 158°F)
- Digital Optical Monitoring Capability: Yes
