NEXEN 966241 ROD LOCK
Quick Overview
Manufactured By: NEXEN GROUP
Manufacturer Part Number: 966241
IMS Product Code: 2131805
Packaging: Sold Individually
Description:
Nexen 966241 Rod Lock
Spring-engaged, stand-alone rod lock with safety rating and enclosed design.
Specifications
- Air chamber volume: 0.680 in
- Approximate engagement response time: 45 ms
- CE certified: CE
- Engagement method: Spring
- Finish: Bare Aluminum
- IEC IP rating: IP67
- Inlet size: 0.125-27 NPTF
- Length: 2.91 in
- Linear holding force: 491 lbf
- Manual release feature: No
- Materials of construction: Brushed Aluminum
- Max allowable pressure (psi): 120
- Max ambient temperature: 150 F, Continuous
- Max intermittent ambient temperature: 212 F, Intermittent
- Max operating pressure (psi): 80
- Min ambient temperature (F): 33
- Min release pressure (bar): 4.137 bar
- Min release pressure (psi): 60
- Mounting style: Stand Alone
- Number of slots for operating mode sensors: 1 Sensor Slot, None included, sold separately as accessory
- Open or enclosed design: Enclosed
- Release method: Air
- Rod diameter: 0.625 in
- Rod requirements: HRC60 Or Hard Chrome Plated Minimum Of 20 Microns, h8 Tolerance, Roughness 1.6 Microns
- RoHS compliant: RoHS
- Safety rating: NexSafe Certified
- Static b10/b10d cycle life: 1000000/2000000
- Unit height: 5.5 in
- Unit width: 3 in, X2
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
