NIBCO LD3022 BUTTERFLY VALVE
Quick Overview
Manufactured By: NIBCO
Manufacturer Part Number: LD3022
IMS Product Code: 1877768
Packaging: Sold Individually
Description:
Nibco LD3022 Butterfly Valve
Ductile iron lug-type butterfly valve with stainless steel disc, EPDM seat, and locking lever handle. Quarter-turn operation, extended neck for insulation up to 2 inches. Recommended for chemical applications.
Specifications
- Valve Size: 4 in
- Valve Type: Butterfly Valve
- Material: Ductile Iron, EPDM, Stainless Steel
- End Connections: Lug
- Valve Body Material: Ductile Iron
- Valve Disc Material: Stainless Steel
- Valve Operator: Locking Lever Handle
- Valve Seat Material: EPDM
- Pressure Class: 250#
- Maximum Temperature: 250 degrees
- Valve Pressure Rating: 250 psi
- Operating Temperature: 225F continuous and 250F intermittent
- Turns/Operation: Quarter-Turn
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 2 In Stock
Ships today if ordered in the next 8 hours and 58 minutes.
