NSK 1314J SELF-ALIGNING BALL BEARING
Quick Overview
Manufactured By: NSK
Manufacturer Part Number: 1314J
IMS Product Code: 2139689
Packaging: Sold Individually
Description:
NSK 1314J Self-Aligning Ball Bearing
Self-aligning ball bearing with 70 mm bore, 150 mm outside diameter, and 35 mm width. Features a straight bore, open closure, and steel cage.
Specifications
- Bore Type: Straight
- Bore Diameter: 70 mm
- Outside Diameter: 150 mm
- Overall Width: 35 mm
- Closure Type: Open
- Contact Angle: Not Applicable
- Internal Clearance: C0
- Seal Type: Open
- Precision Rating: ABEC1, P0
- Bearing Type: Self-Aligning Ball Bearings
- Max Rpm: 4800 rpm
- Cage Material: Steel Cage
- Finish Coating: Uncoated
- Series: 1300
- Radial Dynamic Load Capacity: 75000 N
- Basic Dynamic Load Rating: 75 kN
- Basic Static Load Rating: 27.7 kN
- Grease Limiting Speed: 4000 r/min
- Oil Limiting Speed: 5000 r/min
