NSK 51204 BALL THRUST BEARING
Quick Overview
Manufactured By: NSK
Manufacturer Part Number: 51204
IMS Product Code: 1809001
Packaging: Sold Individually
Description:
NSK 51204 Ball Thrust Bearing
Single-Direction, 20 mm Bore, 40 mm OD, 14 mm Width, Separable
Specifications
- Bore Type: Round
- Thrust Bearing Type: Single-Direction
- Bore Diameter: 20 mm
- Outside Diameter: 40 mm
- Overall Width: 14 mm
- Outside Diameter Design: Straight
- Closure Type: Open
- Separable Or Banded: Separable
- Race Type: Flat
- Precision Rating: ABEC1, P0
- Radial Dynamic Load Capacity: 5050 lbf
- Operating Temperature Range: Maximum of +120 degrees C
- Max Rpm: 6300 rpm
- Cage Material: Steel Cage
- Fillet Radius: 0.6 mm
- Series: 51200
- Weight: 0.077 kg
- Dynamic Load Rating: 22.5 kN
- Static Load Rating: 37.5 kN
- Grease Limiting Speed: 4300 rpm
- Oil Limiting Speed: 6300 rpm
