NSK 6209VVC3 DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NSK
Manufacturer Part Number: 6209VVC3
IMS Product Code: 1908685
Packaging: Sold Individually
Description:
NSK 6209VVC3 Deep Groove Ball Bearing
Deep groove ball bearing with 45 mm bore diameter, dual non-contact rubber seals on both sides providing low-friction sealing. C3 radial internal clearance accommodates thermal expansion and suitable for applications such as electric motors, pumps, fans, and general industrial uses.
Specifications
- d: 45 mm
- D: 85 mm
- B: 19 mm
- r (min.): 1.1 mm
- Cr: 34500 N
- C0r: 20400 N
- Grease lubrication speed rating: 9000 min-1
- da (min.): 51.5 mm
- Da (max.): 78.5 mm
- ra (max.): 1 mm
- Mass: 0.42 kg
- Seal Type: Non Contact Rubber Seals on Both Sides of Bearing
- Radial Internal Clearance: Greater Than Normal
- Type: Single Row Ball Bearing
- Material: Chrome steel, high-precision industrial grade
