NSK 6307ZC3 DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NSK
Manufacturer Part Number: 6307ZC3
IMS Product Code: 1819440
Packaging: Sold Individually
Description:
NSK 6307ZC3 Deep Groove Ball Bearing
Deep groove ball bearing with metal shields on both sides and C3 internal clearance. Features a 35 mm bore diameter and 80 mm outside diameter. Suitable for electric motors, pumps, fans, and general industrial applications.
Specifications
- Bore Diameter: 35 mm
- Outside Diameter: 80 mm
- Width: 21 mm
- Number of Rows: 1
- Radial Internal Clearance: +.0006 to +.0013 in
- Closure Type: Single Shield
- Load Capacity: 35000 N Dynamic/19200 N Static
- Cage Material: Steel
- Maximum Speed: 10000 rpm Grease/12000 rpm Oil
- Temperature Rating: -10 to 110 deg C
- Weight: 1.027 lb
