NSK 6804ZZ DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NSK
Manufacturer Part Number: 6804ZZ
IMS Product Code: 2155055
Packaging: Sold Individually
Description:
NSK 6804ZZ Deep Groove Ball Bearing
Single row, double shielded, steel cage, 20 mm bore diameter, 32 mm outside diameter, 7 mm width
Specifications
- Bore Type: Straight
- Bore Diameter: 20 mm
- Outside Diameter: 32 mm
- Overall Width: 7 mm
- Closure Type: Double Shielded
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Bearing Type: Radial & Deep Groove Ball Bearings
- Internal Clearance: C0
- Operating Temperature Range: -10 to +110 degrees C
- Precision Rating: Not Rated
- Finish Coating: Uncoated
- Cage Material: Steel
- Max Rpm: 26000 rpm
- Series: 6800
- Radial Dynamic Load Capacity: 4000 N
- Radial Static Load Capacity: 2470 N
- Weight: 0.017 kg
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 3 In Stock
Ships today if ordered in the next 10 hours and 44 minutes.
