NTN BEARING 6206ZZC3/EM DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN BEARING
Manufacturer Part Number: 6206ZZC3/EM
IMS Product Code: 1871516
Packaging: Sold Individually
Description:
Ntn Bearing 6206ZZC3/EM Deep Groove Ball Bearing
Deep Groove Ball Bearing, Double Shielded, High Carbon Chrome Steel, 30 mm ID, 62 mm OD, 16 mm Width
Specifications
- Type: Deep Groove Ball Bearing
- Bore Type: Round
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Limiting Speed - Grease: 11000 RPM
- Precision: ISO Class 0
- Radial Internal Clearance: C3
- Static Load Rating: 2540 lbf, 11300 N, 11.30 kN
- Dynamic Load Rating: 4850 lbf, 21600 N, 21.60 kN
- Enclosure: Double Shielded
- Weight: 0.437 lb, 0.198 kg
- Operating Temperature Range: -40 to 250 degrees F, -40 to 120 degrees C
- d: 1.1811 in, 30.000 mm
- D: 2.4409 in, 62.000 mm
- B: 0.6299 in, 16.000 mm
- r: 0.0394 in, 1.000 mm
- r1: 0.0197 in, 0.500 mm
- da min: 1.3780 in, 35.000 mm
- Da max: 2.2441 in, 57.000 mm
- ras max: 0.0394 in, 1.000 mm
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 15 hours and 12 minutes.
