NTN 6002Z DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6002Z
IMS Product Code: 1993815
Packaging: Sold Individually
Description:
NTN 6002Z Deep Groove Ball Bearing
Single Row Radial Ball Bearing - Single Shielded
Specifications
- Type: Deep Groove Ball Bearing
- Bore Type: Round
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Limiting Speed - Oil: 26000 RPM
- Limiting Speed - Grease: 22000 RPM
- Precision: ISO Class 0
- Configuration: One
- Radial Internal Clearance: CN
- Static Load Rating: 635 lbf, 2840 N, 2.84 kN
- Dynamic Load Rating: 1390 lbf, 6200 N, 6.20 kN
- Enclosure: Single Shielded
- Weight: 0.064 lb, 0.029 kg
- Operating Temperature Range: -40 to 250 degrees F, -40 to 120 degrees C
- d: 0.5906 in, 15.000 mm
- D: 1.2598 in, 32.000 mm
- B: 0.3543 in, 9.000 mm
- r: 0.0118 in, 0.300 mm
- r1: 0.0118 in, 0.300 mm
- da min: 0.6693 in, 17.000 mm
- Da max: 1.1811 in, 30.000 mm
- ras max: 0.0118 in, 0.300 mm
New - Missing Box (Special):
Has attachment
Availability: 1 In Stock
Ships today if ordered in the next 1 hours and 58 minutes.
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 3 In Stock
Ships today if ordered in the next 1 hours and 58 minutes.
Used (Special):
These have two bearings on the inside however these items do not have the piece to hold them together.
Availability: 30 In Stock
Ships today if ordered in the next 1 hours and 58 minutes.
