NTN 6004LLU DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6004LLU
IMS Product Code: 2136269
Packaging: Sold Individually
Description:
NTN 6004LLU Deep Groove Ball Bearing
Single Row Radial Ball Bearing - Double Sealed (Contact Rubber Seal)
Specifications
- Type: Deep Groove Ball Bearing
- Bore Type: Round/Straight
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Seal Type: Contact
- Seal Material: Nitrile Rubber
- Precision: ISO Class 0
- Configuration: Single Row
- Radial Internal Clearance: CN
- Static Load Rating: 1140 lbf, 5050 N, 5.05 kN
- Dynamic Load Rating: 2330 lbf, 10400 N, 10.40 kN
- Enclosure: Double Sealed
- Weight: 0.150 lb, 0.068 kg
- Operating Temperature Range: -40 to 250 ºF, -40 to 120 ºC
- Inside Diameter (d): 0.7874 in, 20.000 mm
- Outside Diameter (D): 1.6535 in, 42.000 mm
- Width (B): 0.4724 in, 12.000 mm
- Fillet Radius (r): 0.0236 in, 0.600 mm
- Series: 60 Series
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 8 In Stock
Ships today if ordered in the next 15 hours and 27 minutes.
