NTN 6008ZZC3/EM DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6008ZZC3/EM
IMS Product Code: 1898556
Packaging: Sold Individually
Description:
NTN 6008ZZC3/EM Deep Groove Ball Bearing
Double Shielded, High Carbon Chrome Steel, Pressed Steel Cage, 40 mm Bore Diameter, 68 mm Outside Diameter, 15 mm Width, C3 Radial Internal Clearance, ISO Class 0 Precision
Specifications
- Bore Type: Round
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Limiting Speed - Grease: 10000 RPM
- Precision: ISO Class 0
- Radial Internal Clearance: C3
- Static Load Rating: 2590 lbf, 11500 N
- Dynamic Load Rating: 4180 lbf, 18600 N
- Enclosure: Double Shielded
- Weight: 0.412 lb, 0.187 kg
- Operating Temperature Range: -40 to 250 F, -40 to 120 C
- d: 1.5748 in, 40.000 mm
- D: 2.6772 in, 68.000 mm
- B: 0.5906 in, 15.000 mm
- r: 0.0394 in, 1.000 mm
- r1: 0.0197 in, 0.500 mm
- da min: 1.7717 in, 45.000 mm
- Da max: 2.4803 in, 63.000 mm
- ras max: 0.0394 in, 1.000 mm
