More Views
NTN 606Z SINGLE ROW RADIAL BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 606Z
IMS Product Code: 2173867
Packaging: Sold Individually
Description:
NTN 606Z Single Row Radial Ball Bearing
Single Row Radial Ball Bearing - Single Shielded
Specifications
- Type: Miniature / Extra Small Ball Bearing
- Bore Type: Round
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Limiting Speed - Oil: 42000 RPM
- Limiting Speed - Grease: 35000 RPM
- Precision: ISO Class 0
- Configuration: One
- Radial Internal Clearance: CN
- Static Load Rating: 194 lbf, 865 N, 0.87 kN
- Dynamic Load Rating: 540 lbf, 2430 N, 2.43 kN
- Enclosure: Single Shielded
- Weight: 0.013 lb, 0.006 kg
- Operating Temperature Range: -40 to 250 F, -40 to 120 C
- d: 0.2362 in, 6.000 mm
- D: 0.6693 in, 17.000 mm
- B: 0.2362 in, 6.000 mm
- r: 0.0118 in, 0.300 mm
- da min: 0.3150 in, 8.000 mm
- Da max: 0.5906 in, 15.000 mm
- ras max: 0.0118 in, 0.300 mm
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 2 In Stock
Ships today if ordered in the next 44 minutes.
