NTN 6200LB DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6200LB
IMS Product Code: 2123134
Packaging: Sold Individually
Description:
NTN 6200LB Deep Groove Ball Bearing
Single Row Radial Ball Bearing - Single Sealed (Non-Contact Rubber Seal)
Specifications
- Type: Deep Groove Ball Bearing
- Bore Type: Round
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Limiting Speed - Oil: 30000 RPM
- Limiting Speed - Grease: 25000 RPM
- Seal Type: Non-Contact
- Seal Material: Nitrile Rubber
- Precision: ISO Class 0
- Configuration: One
- Radial Internal Clearance: CN
- Static Load Rating: 537 lbf/2390 N/2.39 kN
- Dynamic Load Rating: 1270 lbf/5650 N/5.65 kN
- Enclosure: Single Sealed
- Weight: 0.071 lb/0.030 kg
- Operating Temperature Range: -40 to 250 ºF/-40 to 120 ºC
- d: 0.3940 in/10.000 mm
- D: 1.1811 in/30.000 mm
- B: 0.3543 in/9.000 mm
- r: 0.0236 in/0.600 mm
- r1: 0.0197 in/0.500 mm
- da min: 0.5512 in/14.000 mm
- da max: 0.6299 in/16.000 mm
- Da max: 1.0236 in/26.000 mm
- ras max: 0.0236 in/0.600 mm
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
