NTN 6200LLUC3/EM DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6200LLUC3/EM
IMS Product Code: 1834237
Packaging: Sold Individually
Description:
NTN 6200LLUC3/EM Deep Groove Ball Bearing
Single Row Radial Ball Bearing - Double Sealed (Contact Rubber Seal), Round Bore, 10 mm ID, 30 mm OD, 9 mm Width, High Carbon Chrome Steel, Pressed Steel Cage, Nitrile Rubber Seal
Specifications
- Bore Type: Straight
- Bore Diameter: 10 mm
- Outside Diameter: 30 mm
- Overall Width: 9 mm
- Closure Type: Double Sealed
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Internal Clearance: C3
- Operating Temperature Range: -40 to 250 F
- Cage Type: Pressed
- Precision Rating: ISO Class 0
- Finish Coating: Uncoated
- Bearing Material: High Carbon Chrome Steel
- Cage Material: Steel
- Seal Material: Nitrile Rubber
- Radial Dynamic Load Capacity: 1270 lbf
- Radial Static Load Capacity: 535 lbf
- Weight: 0.07 lbs
- Limiting Speed - Grease: 18000 RPM
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 29 In Stock
Ships today if ordered in the next 15 hours and 16 minutes.
