NTN 6201ZC3 DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6201ZC3
IMS Product Code: 2138056
Packaging: Sold Individually
Description:
NTN 6201ZC3 Deep Groove Ball Bearing
Single Row Radial Ball Bearing - Single Shielded
Specifications
- Type: Deep Groove Ball Bearing
- Bore Type: Round
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Limiting Speed - Oil: 26000 RPM
- Limiting Speed - Grease: 22000 RPM
- Precision: ISO Class 0
- Radial Internal Clearance: C3
- Static Load Rating: 620 lbf, 2750 N, 2.75 kN
- Dynamic Load Rating: 1510 lbf, 6750 N, 6.75 kN
- Enclosure: Single Shielded
- Weight: 0.079 lb, 0.036 kg
- Operating Temperature Range: -40 to 250 ºF, -40 to 120 ºC
- d: 0.4724 in, 12.000 mm
- D: 1.2598 in, 32.000 mm
- B: 0.3937 in, 10.000 mm
- r: 0.0236 in, 0.600 mm
- r1: 0.0197 in, 0.500 mm
- da min: 0.6299 in, 16.000 mm
- da max: 0.6693 in, 17.000 mm
- Da max: 1.1024 in, 28.000 mm
- ras max: 0.0236 in, 0.600 mm
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 11 In Stock
Ships today if ordered in the next 11 hours and 24 minutes.
