NTN 6206Z DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6206Z
IMS Product Code: 2121320
Packaging: Sold Individually
Description:
NTN 6206Z Deep Groove Ball Bearing
Single Row Radial Ball Bearing - Single Shielded
Specifications
- Type: Deep Groove Ball Bearing
- Bore Type: Straight
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Limiting Speed - Oil: 13000 RPM
- Limiting Speed - Grease: 11000 RPM
- Precision: ISO Class 0
- Radial Internal Clearance: CN
- Static Load Rating: 2540 lbf, 11300 N, 11.30 kN
- Dynamic Load Rating: 4856 lbf, 21600 N, 21.60 kN
- Enclosure: Single Shielded
- Weight: 0.421 lb, 0.190 kg
- Operating Temperature Range: -40 to 250 ºF, -40 to 120 ºC
- Bore Diameter: 30 mm
- Outside Diameter: 62 mm
- Overall Width: 16 mm
- Closure Type: Single Shielded
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Precision Rating: ISO Class 0
- Finish Coating: Uncoated
- Inner Ring Width: 0.6299 in, 16.000 mm
- Fillet Radius: 0.0394 in, 1.000 mm
- Max Rpm: 13000 rpm
- Series: 62
- Radial Dynamic Load Capacity: 4850 lbf
- Radial Static Load Capacity: 2540 lbf
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships today if ordered in the next 13 hours and 4 minutes.
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships today if ordered in the next 13 hours and 4 minutes.
