NTN 6209LLU DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6209LLU
IMS Product Code: 2152697
Packaging: Sold Individually
Description:
NTN 6209LLU Deep Groove Ball Bearing
Single Row Radial Ball Bearing - Double Sealed (Contact Rubber Seal)
Specifications
- Type: Deep Groove Ball Bearing
- Bore Type: Round/Straight
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Limiting Speed - Grease: 5200 RPM
- Seal Type: Contact
- Seal Material: Nitrile Rubber
- Precision: ISO Class 0
- Configuration: One/Single Row Non-Fill Slot
- Radial Internal Clearance: CN
- Static Load Rating: 4586 lbf/20400 N/20.40 kN
- Dynamic Load Rating: 8093 lbf/36000 N/36.00 kN
- Enclosure: Double Sealed
- Weight: 0.884 lb/0.400 kg/398g
- Operating Temperature Range: -40 to 250 degrees F/-40 to 120 degrees C
- d: 1.7720 in/45.000 mm
- D: 3.3465 in/85.000 mm
- B: 0.7480 in/19.000 mm
- r: 0.0433 in/1.100 mm
- r1: 0.0197 in/0.500 mm
- da max: 2.1850 in/55.500 mm
- Da max: 3.0906 in/78.500 mm
- ras max: 0.0394 in/1.000 mm
- Series: 62
