NTN 6215C3 DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6215C3
IMS Product Code: 2123995
Packaging: Sold Individually
Description:
NTN 6215C3 Deep Groove Ball Bearing
Single Row Radial Ball Bearing - Open Type
Specifications
- Bore Type: Round
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Limiting Speed - Oil: 5600 RPM
- Limiting Speed - Grease: 4800 RPM
- Precision: Class 0
- Radial Internal Clearance: C3
- Static Load Rating: 11120 lbf/49500 N/49.50 kN
- Dynamic Load Rating: 16520 lbf/73500 N/73.50 kN
- Enclosure: Open
- Weight: 2.557 lb/1.160 kg
- Operating Temperature Range: -40 to 250 ºF/-40 to 120 ºC
- d: 2.9528 in/75.000 mm
- D: 5.1181 in/130.000 mm
- B: 0.9843 in/25.000 mm
- r: 0.0591 in/1.500 mm
- r1: 0.0197 in/0.500 mm
- da min: 3.2677 in/83.000 mm
- da max: 3.5630 in/90.500 mm
- Da max: 4.8031 in/122.000 mm
- ras max: 0.0591 in/1.500 mm
