NTN 62/22LLU DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 62/22LLU
IMS Product Code: 2155051
Packaging: Sold Individually
Description:
NTN 62/22LLU Deep Groove Ball Bearing
Single Row Radial Ball Bearing - Double Sealed (Contact Rubber Seal)
Specifications
- Type: Deep Groove Ball Bearing
- Bore Type: Round
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Limiting Speed - Grease: 9700 RPM
- Seal Type: Contact
- Seal Material: Nitrile Rubber
- Precision: ISO Class 0
- Configuration: One
- Radial Internal Clearance: CN
- Static Load Rating: 6800 N
- Dynamic Load Rating: 14300 N
- Enclosure: Double Sealed
- Weight: 0.12 kg
- Operating Temperature Range: -40 to 120 degrees C
- d: 22 mm
- D: 50 mm
- B: 14 mm
- r: 1 mm
- r1: 0.5 mm
- da max: 29.5 mm
- Da max: 45 mm
- ras max: 1 mm
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 14 hours and 30 minutes.
