NTN 6807LLU DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6807LLU
IMS Product Code: 2136791
Packaging: Sold Individually
Description:
NTN 6807LLU Deep Groove Ball Bearing
Radial/Deep Groove Ball Bearing - Straight Bore, 35 mm ID, 47 mm OD, 7 mm Width, Double Sealed, Without Snap Ring
Specifications
- Bore Type: Straight
- Bore Diameter: 35 mm
- Outside Diameter: 47 mm
- Overall Width: 7 mm
- Closure Type: Double Sealed
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Internal Clearance: CN
- Operating Temperature Range: -40 to 250 degrees F
- Cage Type: Pressed
- Precision Rating: ISO Class 0
- Finish Coating: Uncoated
- Bearing Material: High Carbon Chrome Steel
- Cage Material: Steel
- Inner Ring Width: 7 mm
- Fillet Radius: 0.3 mm
- Max Rpm: 7600 rpm
- Series: 68
- Radial Dynamic Load Capacity: 1220 lbf
- Radial Static Load Capacity: 910 lbf
- Weight: 0.06 lbs
- Seal Material: Nitrile Rubber
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships on Monday, October 27, 2025
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
